M107 "MAD DOG" - Italeri 248

Specification :
Country of Origin : USA
Manufacturer :
BMY (Bowen-McLaughlin-York), FMC, Pacific Car

Crew (on Gun) : 5
Armament : 1 x 175mm gun M113
Ammunition : 2 x 175mm
Height : 3.679m (top of barrel traveling), 2.809m (top of mount), 1.475m (hull top)
Engine : Detroit Diesel Model 8V-71T, turbocharged, 2 stroke liquid cooled, 8 cylinder diesel developing 405bhp at 2,300 rpm

M107 image 41961. After the nuclear threat had subsided, the next concern of the US Army was to get as much as possible air-portable, and from ponderous turreted bulldogs, they changed overnight to stripped down whippets. Replacements for the 155mm gun and 8-inch howitzer were call for, but instead of the 155mm gun a new caliber was to be adopted, 175mm, since it promised greater range and also a nuclear projectile. The carriage was simply a hull with space for the engine and driver, five road wheels each side, and the gun mounting, together with hydraulic shell-handling machinery. There was the usual hydraulically operated recoil spade at the rear.
(Extracted from : The GreenHill Armoured Fighting Vehicles Data Book)
Length gun forwards : 11.256m (spade up)
Length hull : 5.72m (without gun or spade)
Width : 3.149m
Ground clearance : 0.46m
Ground pressure : 0.81 kg/cm²
Range : 725 km
Fuel capacity : 1,137 lit.
Fording : 1.066m
Vertical Obstacle : 1.066m
Trench : 2.362m
Weight, combat :
28,168 kg
Weight, unloaded : 25,915 kg
Power to weight ratio : 14.37hp/tonne
Maximum road speed : 56 km/hr
Gradient : 60%
Side slope : 30%
Armor : Classified
Armor type : Steel
NBC system : No
Night Vision equipment : Yes (Driver only, passive)
